T30D-24-S352N-04
Database-backed development preview for the AIRTEKPOWER public website.
- Exact model
- T30D-24-S352N-04
- Fan form
- Cross-flow fans
- Motor technology
- DC
- Rated voltage
- 24
- Speed
- 2600
- Current
- 0.14
- Airflow
- 100
- Pressure
- 16
- Diameter
- 30 mm
Product summary not published
Use the verified fields and source attachments below, or request engineering review.
Structured specifications
Mechanical
| Diameter | 30 mmVerified |
|---|
Electrical
| Rated voltage | 24 Verified |
|---|---|
| Current | 0.14 Verified |
| Power | Not published Not published |
| Insulation class | B Verified |
Protection
| Protection class | IPX4 Verified |
|---|
Other published facts
| Speed | 2600 Verified |
|---|---|
| Airflow | 100 Verified |
| Pressure | 16 Verified |
| Impeller length | 352 Verified |
| Dimension A | 406 Verified |
| Dimension B | 362 Verified |
| Dimension C | 352 Verified |
| Material | 铝合金(Aluminum) Verified |
| Ambient temperature | -25~+60 °CVerified |
Data provenance & source records
- Stable ID
- fs.aada48c7f1c65974328b8fc0223a8613c99d2631062d8aaf206e50a1343414ba
- Published revision
- 2
Original technical source values
Values are shown in the source format. Units and operating conditions are not inferred.
| Source field | Original value | State |
|---|---|---|
| 产品一级分类 | 贯流风机(Cross flow fan) | Source value |
| 产品二级分类 | DC贯流风机(DC Cross flow fan) | Source value |
| 电压(Voltage) | 24 | Source value |
| 电流 Current | 0.14 | Source value |
| 转速(Speed) | 2600 | Source value |
| 风压(AIr Pressure) | 16 | Source value |
| 风压（*系数）Air Pressure | 16 | Source value |
| 风量(Air Flow) | 100 | Source value |
| 风量(*系数）Airflow | 102 | Source value |
| 噪声(Noise Level) | 34 | Source value |
| 风轮类型 | single | Source value |
| 叶轮直径 Diameter | 30mm | Source value |
| 叶轮长度 Length | 352 | Source value |
| 尺寸:A | 406 | Source value |
| 尺寸:B | 362 | Source value |
| 尺寸:C | 352 | Source value |
| 当前状态 | ✅ | Source value |
| 对应目录册页码 | 4 | Source value |
| 功率(Power) | / | Source value |
| 风轮材质(Material) | 铝合金(Aluminum) | Source value |
| Amb.Temp | -25~+60℃ | Source value |
| 防护等级Protection Class | IPX4 | Source value |
| 绝缘等级Insulation class | B | Source value |
